Electric Forklift 18

  • Carrying capacity: 18 tons
  • Drive mode: electric
  • Transmission mode: motor drive
  • Battery Type: High-performance lithium battery (or other type of battery)
  • Speed: Optional according to configuration

GET INSTANT QUOTE

    FEATURES

    Product Details

    Description

    The Electric Forklift 18 is an electric forklift designed for heavy material handling. Its powerful load carrying capacity and efficient electric drive system make it a useful tool in modern logistics, warehousing and industrial manufacturing. This forklift not only has excellent performance, but also focuses on the safety and comfort of operation to meet a variety of complex and heavy handling needs.

    Strong load capacity

    Electric Forklift 18 has a load capacity of up to 18 tons, which can easily handle a variety of heavy material handling tasks, such as large cargo, machinery and equipment.

    Efficient electric drive

    The advanced electric drive system provides strong and stable power for the forklift to ensure that the handling task can be efficiently and reliably completed in a variety of working environments.

    Environmental protection and energy saving

    The electric drive mode achieves zero emission and low noise operation, which not only meets environmental requirements, but also helps to reduce energy consumption and operating costs.

    Safety and reliability

    The forklift is equipped with multiple safety protection devices, such as emergency braking, overload protection, etc., to ensure the safety of operators and cargo during handling. At the same time, its rugged structure and high-quality material selection ensure the long-term stable operation of the forklift.

    Ease of operation

    Electric Forklift 18 uses a user-friendly design, the operation interface is simple and easy to understand, the operator can quickly pick up and master the functions. In addition, its electric steering system, speed control system, hydraulic control system and braking system are controlled by electrical signals, making the operation easier and more flexible.

    Comfortable seats

    ergonomically designed seats provide a comfortable driving experience for the operator.

    Operation interface

    Simple and intuitive operation interface, so that operators can easily get started, quickly grasp the functions.

    Easy maintenance

    The design of the electric forklift takes into account easy maintenance and maintenance factors, reducing maintenance costs and time.

    The Electric Forklift 18 is the ideal choice for modern logistics, warehousing and industrial manufacturing with its powerful carrying capacity, efficient electric drive system, environmental protection and energy saving features, and user-friendly design. We are committed to providing our customers with quality products and services to help them achieve more efficient and environmentally friendly material handling solutions.

    Specifications

    型     号       Model   CPD18
    动力种类 Power type   Battery
    额定起重量 Rated load KG 1800
    载荷中心距 Load center distance mm 500
    驾驶方式 Driving type   Seat
     Length 有货叉 With fork   L1    mm 3190
      无货叉 Without fork  L2   2120
         全宽   Whole Width    B   1010
    Height  Mast lowered height     H1   1960
         Overhead guard height            H2   2070
       Max working Height          H3   4050
     Distance from seat to top light   L3   1000
     轴距     Wheel  base       L4   1260
     前悬距  Front overhang       Y   350
     后悬距    Back overhang    L5   365
     前轮距  Front wheel tread    R   1010
     后轮距   Back wheel tread    P   830
      Min Floor clearance     F   130
      Max lifting height       H   3000
      Free lifting height      H4   40
      Fork  changing        S   1040/200
      Min Turning radius     WA   2100
     Min driiving width       RA   3850
      门架倾角(前/后)Tilt  angle   a/β ° 6/12
    Max lifting speed without goods mm/s 300
    Max lifting speed with full  goods   260
    Max speed without goods Km/h 14
    Max speed with full goods   13
     Max climbing angle ≤15
     Whole weight Kg 2420
    车轮数量(前/后)Driving Wheel   2/2
    轮胎类型(前/后)Type model   pneumatic tire
    轮胎尺寸(前)Front Tyre   18×7-10
    轮胎尺寸(后)Rear Tyre   16×6-8
    制动器/行车制动器 Hand Brake   Hydraulic Pedal
    停车制动器 Brake  type   M-Hand
    蓄电池电压/容量 Battery Volt/ capacity V/Ah 48/230
    驱动电机功率 Driving motor power Kw 5AC
    油泵电机功率 pump power   6DC

    Vedio

    Certificate

    Custom Containers FAQs

    Qigao is a welder and flame cutting machines leader in China. We insists on supplying professional technology, high performance and good after-sale service to meet the requirements of customers from around the worlds. China Qigao will try our best to become your one-stop supplier. Name your detailed task and we will find a solution together!

    These oxy-fuel flame gas cutting machine are well used in shipbuilding, oil production, metallurgy, metal structure and other manufacturers etc.

    Different sizes of the cutting tips, different cutting thickness. First confirm the needed cutting thickness, then select the corresponding cutting nozzles. See below detailed parameter of G02 (acetylene)and G03 (propane)tips.

    TypeNo.Gas cutting
    aperture(mm)
    Cutting
    Thickness(mm)
    Cutting speed
    (mm/min)
    Oxygen
    pressure(Mpa)
    Acetylene
    pressure(Mpa)
    Acetylene
    GO₂
    #000.85-10600-4500.2-0.3>0.03
    #01.010-20480-3800.2-0.30.03
    #11.220-30400-3200.25-0.350.03
    #21.430-50350-2800.25-0.350.03
    #31.650-70300-2400.3-0.40.04
    #41.870-90260-2000.3-0.40.04
    #5290-120210-1700.4-0.60.04
    #62.4120-160180-1400.5-0.80.05
    #72.8160-200150-1100.6-0.90.05
    #83.2200-28090-600.6-1.00.05
    #93.6270-35090-600.7-1.10.05
    #104350-40070-500.7-1.20.06



    Type

    No.

    Gas cutting
    aperture(mm)

    Cutting
    thickness(mm)

    Cutting speed
    (mm/min)

    Oxygen
    pressure(Mpa)

    Acetylene
    pressure(Mpa)

    Propane
    GO3

    #0

    0.7

    5-10

    800-450

    0.2-0.3

    >0.03

    #1

    0.9

    10-20

    480-300

    0.2-0.3

    0.03

    #2

    1.2

    20-35

    400-320

    0.3-0.4

    0.03

    #3

    1.5

    35-60

    350-280

    0.3-0.4

    0.03

    #4

    1.8

    60-90

    300-240

    0.4-0.6

    0.04



    #5

    2.1

    90-130

    260-200

    0.4-0.6

    0.04

    #6

    2.5

    130-180

    220-180

    0.4-0.6

    0.04

    #7

    2.7

    180-250

    200-160

    0.5-0.7

    0.05

    #8

    3.1

    250-330

    180-140

    0.5-0.7

    0.05

    #9

    3.5

    330-380

    130-90

    0.6-0.8

    2.05

    #10

    4.0

    380-450

    90-50

    0.6-0.8

    0.05

    Yes, they can. Our standard machines are with the circling-parts to do extra circling cutting, including their main straight-line cutting function. What’s more, the plasma cutting also is available.

    The main differences between CG1-30A and CG1-30B is the working rail. 30A is with “H” rail, 30B is with hole rail. You can select the wanted rail before confirm the order. The rail is different, the price will be different.

    MIG welders, TIG welders, MMA welders, hand spot welding machines, welding carriage and portable spot welding machines, stud welding machines and so on.

    What is the warranty time for welding and cutting machines.
