Electric Forklift 16

  • Carrying capacity: 16 tons
  • Drive mode: electric
  • Transmission mode: motor drive
  • Battery Type: High-performance lithium battery (or other type of battery)
  • Speed: Optional according to configuration

GET INSTANT QUOTE

    FEATURES

    Product Details

    Description

    The Electric Forklift 16 is an electric forklift designed for medium and large material handling. With its excellent load carrying capacity, efficient electric drive system and advanced handling technology, this forklift truck is the right hand for modern logistics, warehousing and industrial manufacturing.

    Strong load capacity

    Electric Forklift 16 has a load capacity of up to 16 tons, which can easily handle the handling needs of various medium and large materials.

    Efficient electric drive

    The advanced electric drive system provides stable and powerful power for the forklift to ensure that the handling task can be efficiently and reliably completed in a variety of working environments.

    Environmental protection and energy saving

    The electric drive mode achieves zero emission and low noise operation, which not only meets environmental requirements, but also helps to reduce energy consumption and operating costs.

    Advanced control technology

    equipped with intelligent control system and humanized operation interface, the operation of forklift truck is more simple and accurate, and the operation efficiency and safety are improved.

    Multiple safety protection

    The use of multiple safety protection devices, such as emergency braking, overload protection, etc., to ensure the safety of operators and cargo.

    Electric Forklift 16 offers the following significant advantages in its category:

    Strong carrying capacity

    It can meet the handling needs of medium and large materials and improve working efficiency.

    Efficient electric drive

    Stable and powerful power output to ensure that handling tasks can be efficiently completed in a variety of working environments.

    Environmental protection and energy saving

    zero emission, low noise operation, in line with environmental requirements, reduce energy consumption and operating costs.

    Advanced control technology

    intelligent control system and humanized operation interface make the operation of forklift more simple and accurate, improve work efficiency and safety.

    Customized service

    We can customize the forklift according to the specific needs of customers, including the adjustment of bearing capacity, lifting height, driving speed and other parameters to meet the needs of different occasions.

    In summary, the Electric Forklift 16 is an efficient, environmentally friendly, safe and reliable electric forklift for a variety of medium and large material handling scenarios. We are committed to providing our customers with quality products and services to help them achieve more efficient and environmentally friendly material handling solutions.

    Specifications

    型     号       Model CPD16
    动力种类 Power type Battery
    额定起重量 Rated load KG 1600
    载荷中心距 Load center distance mm 500
    驾驶方式 Driving type Seat
     Length 有货叉 With fork   L1    mm 3040
    无货叉 Without fork  L2 1970
         全宽   Whole Width    B 1010
    Height  Mast lowered height        H1 1960
       Overhead guard height                     H2 2070
     Max working Height           H3 4050
     Distance from seat to top light   L3 1000
     轴距     Wheel  base       L4 1260
     前悬距  Front overhang       Y 350
     后悬距    Back overhang    L5 365
     前轮距  Front wheel tread    R 1010
     后轮距   Back wheel tread    P 830
      Min Floor clearance     F 130
      Max lifting height       H 3000
      Free lifting height      H4 40
      Fork  changing        S 1040/200
      Min Turning radius     WA 2100
     Min driiving width       RA 3850
      门架倾角(前/后)Tilt  angle   a/β ° 6/12
    Max lifting speed without goods mm/s 300
    Max lifting speed with full  goods 260
    Max speed without goods Km/h 14
    Max speed with full goods 13
     Max climbing angle ≤15
     Whole weight Kg 2380
    车轮数量(前/后)Driving Wheel 2/2
    轮胎类型(前/后)Type model Solid tire
    轮胎尺寸(前)Front Tyre 18×7-10
    轮胎尺寸(后)Rear Tyre 16×6-8
    制动器/行车制动器 Hand Brake Hydraulic Pedal
    停车制动器 Brake  type M-Hand
    蓄电池电压/容量 Battery Volt/ capacity V/Ah 48V/230
    驱动电机功率 Driving motor power Kw 5AC
    油泵电机功率 pump power 6DC



    Vedio

    Certificate

    Custom Containers FAQs

    Qigao is a welder and flame cutting machines leader in China. We insists on supplying professional technology, high performance and good after-sale service to meet the requirements of customers from around the worlds. China Qigao will try our best to become your one-stop supplier. Name your detailed task and we will find a solution together!

    These oxy-fuel flame gas cutting machine are well used in shipbuilding, oil production, metallurgy, metal structure and other manufacturers etc.

    Different sizes of the cutting tips, different cutting thickness. First confirm the needed cutting thickness, then select the corresponding cutting nozzles. See below detailed parameter of G02 (acetylene)and G03 (propane)tips.

    TypeNo.Gas cutting
    aperture(mm)
    Cutting
    Thickness(mm)
    Cutting speed
    (mm/min)
    Oxygen
    pressure(Mpa)
    Acetylene
    pressure(Mpa)
    Acetylene
    GO₂
    #000.85-10600-4500.2-0.3>0.03
    #01.010-20480-3800.2-0.30.03
    #11.220-30400-3200.25-0.350.03
    #21.430-50350-2800.25-0.350.03
    #31.650-70300-2400.3-0.40.04
    #41.870-90260-2000.3-0.40.04
    #5290-120210-1700.4-0.60.04
    #62.4120-160180-1400.5-0.80.05
    #72.8160-200150-1100.6-0.90.05
    #83.2200-28090-600.6-1.00.05
    #93.6270-35090-600.7-1.10.05
    #104350-40070-500.7-1.20.06



    Type

    No.

    Gas cutting
    aperture(mm)

    Cutting
    thickness(mm)

    Cutting speed
    (mm/min)

    Oxygen
    pressure(Mpa)

    Acetylene
    pressure(Mpa)

    Propane
    GO3

    #0

    0.7

    5-10

    800-450

    0.2-0.3

    >0.03

    #1

    0.9

    10-20

    480-300

    0.2-0.3

    0.03

    #2

    1.2

    20-35

    400-320

    0.3-0.4

    0.03

    #3

    1.5

    35-60

    350-280

    0.3-0.4

    0.03

    #4

    1.8

    60-90

    300-240

    0.4-0.6

    0.04



    #5

    2.1

    90-130

    260-200

    0.4-0.6

    0.04

    #6

    2.5

    130-180

    220-180

    0.4-0.6

    0.04

    #7

    2.7

    180-250

    200-160

    0.5-0.7

    0.05

    #8

    3.1

    250-330

    180-140

    0.5-0.7

    0.05

    #9

    3.5

    330-380

    130-90

    0.6-0.8

    2.05

    #10

    4.0

    380-450

    90-50

    0.6-0.8

    0.05

    Yes, they can. Our standard machines are with the circling-parts to do extra circling cutting, including their main straight-line cutting function. What’s more, the plasma cutting also is available.

    The main differences between CG1-30A and CG1-30B is the working rail. 30A is with “H” rail, 30B is with hole rail. You can select the wanted rail before confirm the order. The rail is different, the price will be different.

    MIG welders, TIG welders, MMA welders, hand spot welding machines, welding carriage and portable spot welding machines, stud welding machines and so on.

    What is the warranty time for welding and cutting machines.
